BilicareFocus
Overview
Special Functions
Invention at a glance
The phototherapy system achieves an irradiance of 25 to over 45 mw/cm² from a distance of 18 inches (45 cm). It uses a faceted LED panel and special 30-degree lenses to focus the blue light directly on the baby tray, preventing light wastage and room pollution. LEDs are positioned in three-dimensional angles for maximum focus on the treatment area. The system features three modes of phototherapy, allowing different wavelengths to treat neonatal jaundice based on serum bilirubin levels without needing to adjust the light source distance. The aluminum LED enclosure serves as a heat sink, eliminating the need for a cooling fan, while Cree LEDs reduce heat and enhance light output, extending the life of the system and ensuring energy efficiency.
- Irradiance: 25 to > 45 mw/cm² from 18 inches.
- 3D angled LEDs with 30-degree lens for focused blue light.
- Three phototherapy modes based on bilirubin levels.
- No cooling fan required; aluminum enclosure acts as heat sink.
- Cree LEDs reduce heat and extend lifespan.
- Energy-efficient, using only 50% power.
- Sleek design with a durable, unbreakable baby bassinet.
- Smart controller for usage hours, treatment time, feeding schedule, and irradiance control.
- Irradiance of 25 to > 45 mw/cm² is achieved from a distance of 18 inches (45 cm).
- Faceted LED panel to focus the blue light only on the baby tray and avoid wastage of light, reducing light pollution in the room.
- LEDs fixed in different 3D angles to focus the blue light more effectively.
- Special 30-degree lens used to focus blue light on the baby’s treatment area.
- Three modes of phototherapy treatment incorporated, providing different wavelengths from a distance of 18 inches to treat neonatal jaundice based on serum bilirubin levels, eliminating the need to reduce the distance between the light source and the baby bassinet.
- No need for a special cooling fan, as the LED enclosure is made from an aluminum box that acts as a heat sink to absorb heat produced by the LEDs.
- Special Cree LEDs used, which produce less heat and dissipate more light.
- Almost doubles the life of the LED, as the irradiance of 25 mw/cm² is achieved using only 50% of power, reducing light wastage.
- Economical for hospitals as electricity consumption is reduced.
- Economical for patients, as the hospital stay is reduced.
- Sleek and elegant design of the phototherapy unit and unbreakable baby bassinet not only enhance the ambience but also ensure durability.
- Smart controller indicates phototherapy usage hours, treatment time, infant feed schedule, and also controls the irradiance.
